VoBo HL-1
From: $695.00
A universal LoRaWAN bridge, certified for use in Class1 Div 2 hazardous locations, converting wired sensors and transmitters into LoRaWAN enabled wireless long-range devices.
Contact Volley Boast for VoBoAnalytics options and pricing.
Product Details
A universal LoRaWAN bridge, certified for use in hazardous locations, converting wired sensors and transmitters into LoRaWAN enabled wireless long-range devices.
- LoRaWAN 1.0.4 compliant, backwards compatible
- US915 (902-928 MHz) channel plan
- Powered by a D-Cell user-replaceable primary battery. The battery has an expected life of 5+ years.
- Up to 6 miles transmission range (line of sight).
- Universal I/O – each VoBo Endpoint has:
- 3 Analog inputs, GP-1 supplies 5 to 24 volts to terminals for sensor power supply. Jumper selectable between Voltage and Current inputs.
- 3 Discrete digital inputs, jumper selectable between dry contact and voltage.
- 1 Discrete Wake-up input.
- 1 Open Drain Output (36V, 1 A max).
- RS485 Modbus RTU Master Terminal (multiple slave optional)
- Available with VoBoSync technology
- Available with optional VoBoAnalytics edge compute capability
- Available with optional multiple Modbus RTU read/write capability
Certified for use in Hazardous Locations:
- ANSI/ISA 12.12.01 and CAN/CSA C22.2 No.213:
- Class I, Division 2, Groups C,D T4
- Class II, Division 2, Groups F,G T135°C
- Class III, Division 1
- IP66/NEMA 4X rated
- Operating temperature -35°C to 80°C
User Manual & Data Sheet:
